3DR Control N1 Flight Controller

  1. Home
  2. › Shop All
$99.99
SD Card *
Thermal Calibration *
Carrier Option : R0026 Cuby
Carrier Option : R0027 Longy
Carrier Option : R0033 FPV
Carrier Option : R0034 CN1 to Control Zero OEM Adapter
Availability: Usually Ships in 5 to 7 weeks

Create Wishlist

Control N1 (CN1) autopilot module isometric view ultra-compact UAV flight controller by 3DR Control N1 (CN1) world’s smallest autopilot module and flight controller bottom view showing connector interface
Control N1 (CN1) autopilot module isometric view ultra-compact UAV flight controller by 3DR
Control N1 (CN1) world’s smallest autopilot module and flight controller bottom view showing connector interface

Control N1 is the world's smallest, lightest, and most versatile high-performance autopilot module. Weighing just 2.38 g and measuring 17.6 × 28.15 mm, it delivers full ArduPilot and PX4 compatibility in an unbelievably compact footprint.

Powered by an STM32H743 processor with advanced sensor fusion, the CN1 brings commercial-grade flight control to even the most space- and weight-constrained UAV and robotics platforms.

Built on over 10 years of flight controller design and development experience.

View Full Documentation

Key Features

  • Ultra-Compact & Feather-Light: Ideal for nano-UAVs, small robotics, ROVs, and embedded systems
  • Single-Sided PCB Architecture: Reducing manufacturing complexity, improving reliability, and minimizing potential failure points
  • Future-Proof Board-to-Board Interface: Hirose DF40 Series connector — RPi CM5-like — with extra signal pins for custom controller or carrier boards
  • Premium Sensor Suite: Dual high-grade IMU sensors, AK09940A magnetometer, and DPS368 barometer — industry-leading performance
  • Open-Source Ecosystem: Compatible with ArduPilot and PX4, offering rich tools and global community resources
  • US-Designed & Manufactured: Built in the USA using trusted components from leading manufacturers (Murata, STMicro, TI, NXP) ensuring industrial-grade reliability

Common Applications

  • Nano-UAVs and micro-air vehicles
  • Sub-250 g platforms
  • Small robotics and automation projects
  • ROVs / UUVs / underwater systems
  • Research, prototyping, and embedded flight-control development
  • Swarm robotics and distributed systems
  • Any vehicle requiring compact, high-performance flight control

Technical Specifications

Core & Processor / Sensors

Main Processor STM32H7, 1 MB RAM, 2 MB FLASH IMUs / Sensors 2 × IIM-42653
Software Compatibility ArduPilot (fully compatible), PX4 (compatible) Magnetometer AK09940A
External Memory 8 MB EEPROM Barometer DPS368

Interfaces / Electrical Power & Environment

Serial & IO 7 × UART, 1 × SPI, 2 × I²C, 1 × SDIO/SDMMC Temperature Range –40°C to +85°C
Other IO 12 × PWM, 4 × Push-Pull direct from MCU, 1 × USB-FS, 1 × Pin from onboard LED (chainable), 1 × SWD, BOOT0 pin Oscillator 24MHz TCXO
RC Protocols All supported by flight stacks Design Single-sided PCB for robust, compact, scalable architectures
Expansion Dedicated expansion port for 3DR sensors Onboard Storage microSD socket

Mechanical / Environmental & Logistics

Dimensions (L × W × H) 17.6 × 28.15 × 3.8 mm (0.69 × 1.11 × 0.15 in) Storage microSD slot — 32 GB included or 8 GB industrial (+ $10)
Weight 2.38 g (0.084 oz) HW Crypto / Hash Optional
Mounting Holes None — single-sided module intended for board-to-board mounting Conformal Coating Contact For Pricing
Connectors Amphenol® BergStak® 2 × 30-pin, 1 × 80-pin Country of Origin USA

What's Included

  • 1 × Control N1 module (bare)
  • 1 × 32 GB microSD card (not included with 8 GB industrial upgrade)

Typical Platforms

Multirotor Fixed-Wing VTOL Rover
Boats / Submarines / UUV Autonomous Tractors Robotics Platforms Others

Available Products To Purchase With Control N1

Additional Information

SKU R0024 ECCN EAR99
Country of Origin USA Tariff Code 9014.20.4000
